Tobee Hydroman THY175-THY220 Hydraulic Dredge Pump

Tobee Hydroman THY175-THY220 Hydraulic Dredge Pumps are suitable for small, medium and large series of Excavators. Besides, they are specialized for those circumstances that are difficult to dig, such as much more water and watery sludge, mud, sand and slurry. Remove the bucket and connect to the hydraulic dredge pump, concentration of extraction with high efficiency and density could be achieved. The work efficiency improves greatly with the matching hydraulic dredge pump and long-distance transportation is also realized. In addition, the Hydroman hydraulic dredge pump could be equipped with hydraulic station and applies to the harsh environment. Hence, several difficulty conditions could be dealt with such as excavators digging ineffectively, long-distance transportation of mud and mortar, lack of electricity supply and frequent switching conditions. In conclusion, it can be supplied to various dredging conditions.

Design Features:

√ The hydraulic dredge pump bottom is arranged with the mixing device, and the bilateral and multilateral separate mixer can be arranged, which can prevent pump blockage by the bulky fixed substance, so as to fully mix the solid with liquid, and facilitate handling.
√ The hydraulic dredge pump can handle the solid substance with the maximum particle size of 150mm, and the solid-liquid extraction concentration can be over 70%.
√ Due to different conditions, the dredge pump output may be changed with influence of the handling medium, field operation, conveying distance and other factors.
