Tobee 4x3D-AHR Rubber Lined Slurry Pump

Tobee 4x3D-AHR Rubber Lined Slurry Pump is a heavy-duty slurry pump handling tough and abrasive duties. Rubber slurry pumps are widely used for continuous pumping of highly abrasive/dense slurries in processes from cyclone feed to regrind, mill discharge, flotation, mine drainage, dredging of settling lagoons and pumping of drilling mud and tailings in mineral plants and other industrial applications.

Design Features:

√ Double-casing design centrifugal rubber lined slurry pump, wide passage for solids

√ Bearing assembly & frame: Both standard & high-capacity types available.

√ A large-diameter shaft with a short overhang minimizes deflection and vibration.

√ Heavy-duty roller bearing is housed in a removable bearing cartridge.

√ Rubber slurry pump body is fastened to the frame with a minimum number of bolts.

√ Slurry pump impeller adjustment is provided in a convenient position below the bearing assembly.

√ Slurry pump impeller & liner material: natural rubber etc.
