Tobee 4x3C-AH Slurry Pump

Tobee 4x3C-AH Slurry Pump is engineered with the latest hydraulic and wear technologies to cope with the most severe corrosive and abrasive slurry applications. The 4x3C-AH pumps feature patented innovative designs that can significantly reduce the operational costs of slurry pumping. It is widely used in industry of mining, electrical power, metallurgy, coal, environmental protection, etc. for transportation of abrasive solid slurry.

Design Features:

√ The 4x3C-AH slurry pump frame plates have replaceable wear-resistant metal liners; impellers & volute liners are made of wear-resistant metal (such as A05, A49, and other high chrome metal).

√ The 4x3C-AH slurry pump bearing assembly uses a cylindrical structure, allowing easy adjustment of the space between the impeller & front liner, and can be completely removed for repair. Grease lubrication.

√ The 4x3C-AH slurry pump shaft seal can use packing seal, expeller seal and mechanical seal. One pump can also use packing seal together with expeller seal.
